Kammprofile gasket with loose outer ring

Kammprofile gasket with loose outer ring

Kammprofile gasket with loose outer ring: The metallic core is made with concentrically grooved profiling on both sides. A notch is turned on the outer circumference of the core in which a loose centering ring. With soft sealing layer in both sides

Model:KXT-720

Send Inquiry

Product Description

Kammprofile gasket with loose outer ring


Style KXT1130 Kammprofile Gasket with Integral Outer Ring

Kammprofile gasket have proven extremely useful in all areas of industry, including the most demanding sealing tasks. Our Kammprofile gaskets

can be found in conventional power plants as well as in the primary circuit of nuclear power plants. In nuclear power plants, they are used e.g. as

a heat exchanger gasket, as a valve cap gasket or as a manhole cover gasket on steam generators or pressurisers



Kammprofile Gasket with Integral Outer Ring is a slight variation than Kammprofile Gasket with loose Outer Ring. The integral outer locating

ring is replaced by a loose fitting, independent, thinner locating ring. The loose fitting ring allows for expansion and contraction without excessive

stress being induced in the solid metal core. Depending on centering ring material and thickness, Kammprofile Gasket with Integral outer ring

may be more economical than Kammprofile Gasket with loose Outer Ring. TKammprofile Gasket with Integral Outer Ring is recommended for

use on standard flat face and raised face flange assemblies.



Advantages

 Outstanding sealing characteristics at a wide range of seating stress levels

 The gasket will not damage the flange surface and can be easily removed

 High resistance to severe temperature & pressure variation

 The gasket cores are reusable reducing cost usage

 Extreme temperature and chemical resistance

 Low initial sealing stress for installation

 Reliable sealing performance

 Can be reused



Application

 High pressure and high temperature applications

 Heat Exchanger and vessel applications

 Small flange widths & damaged flange

 Suitable for a range of chemicals

• Can be used for narrow flanges

 Petrochemical industry

 Coolers., etc



Materials for metal Core

Core Materials

Max Temperature

Core Materials

Max Temperature

Core Thicknes

SS 316L

550 oC

Inconel 625

450 oC

2mm, 3mm, 4mm

SS 304

550 oC

Incoloy 825

450 oC

Monel 400

600 oC

Hastelloy B-2

450 oC

Nickel 200

600 oC

Hastelloy C 276

450 oC

Inconel 600

900 oC

Titanium

350 oC

Face Materials

Max Temp

Face Materials

Max Temp

Graphite

550 oC

PTFE

260 oC

















Standard size

Thickness: 3.5mm, 4.0mm, 4.5mm, 5.0mm
We also provides other sizes, for details please contact us or send your inquiry directly to us
